Description
Technical specification
Remote control ON/OFF by Rs485(this meter don’t have wifi function)
Working voltage: 90-300V 50/60Hz
Start current: 20mA
MAx current: 65A
Comsumption<2w/8VA
Isolation and withstand voltage: 450V
Accuracy class: 1
Display: LCD 6+1 digits
Interface OPEN COLLECTOR OUTPUT(S0) 18-27V 27mA
Impulses: 2000imp/kWh (0.5Wh/Imp)-65A
Working temperature: -25 to 70°c
PINK: Normal operation Flashing rate proportional to load
Installation: Din rail 35mm
Protection: IP20
